ABB - Installation Products 15kv C Am-op Kit
ABB - Installation Products #:655LINKCLRJ0300BDRG
SKU: ABBI655LINKCLRJ0300BDRG
UPC: 783786651696
SKU: ABBI655LINKCLRJ0300BDRG
UPC: 783786651696
Your Price: $6,484.98 / EA
ABB - Installation Products 15kv C Am-op Kit
Ask about this product
Specification Sheet
Weight:
Country of Origin:
Lead Time: 0 Days
Detailed Description
600 Amp, 15kV, Deadbreak Cam-Op Connector Kit with Insulated Cap, Cable Insulation Diameter 0.980 inch to 1.180 inch. Aluminum Compression Lug. Conductor Size AWG or kcmil, Compressed Stranded 350 /Compacted Solid 400 /mmSquared Compact 185.
| Length: | 10 ft |
| Width: | 1-1/2 in |
| Depth: | 1-1/2 in |
| Gauge: | 12 Gauge |
| Finish: | Gold |
| Size: | 20.50 inches from edge of Lever to Bushing Flange |
| Color: | Black |
| Standard: | ANSI/IEEE Standard 386 |
| Insulation: | Yes, EPDM Rubber |
| Temperature Rating: | -40 to +65 C |
| Connection: | Compression |
| Material: | EPDM Rubber |
| Voltage Rating: | 15 kV |
| Amperage Rating: | 600 A |
| Conductor Range: | 350 kcmil , 400 kcmil |
| Type: | Cam_OP Connector Kit |
| Application: | External Visible Break, Testing, Grounding and Isolation |
| Special Features: | Easily Installed or Removed by Hotstick Operation of the Cam Action Disconnect Lever |
