nVent RTB12N WASHER, SS SPP6
$0.00
nVent #: RTB12N
SKU: NVENRTB12N
UPC: 782856966371
SKU: NVENRTB12N
UPC: 782856966371
| Enclosure Rating: | IP 20 |
| Enclosure Material: | UL 94V-0 Thermoplastic |
| Protection Modes: | L-L |
| Connection, Stranded: | #18 min |
| Connection, Solid: | #18 min |
| Status Indication: | Mechanical flag |
| Nominal System Voltage (Un): | 12 VDC |
| Color: | Red |
| Replacement Module: | RTBN12M |
| Max Continuous Operating Voltage (Uc): | 18 VDC |
| Voltage Protection Rating (VPR): | 65 V @ 3 kA L-L |
| Complies With: | AREMA C/S Manual Parts 11.5.1, 11.3.2, 14.1.2 |
| Rated Load Current (IL): | 15 |
| Temperature: | -40-85 |
| Loop Resistance: | 900-900 O |
| Mounting: | 35 mm top hat DIN rail |
| Width: | 18-18 |
| Application: | Surge Protection |
| Type: | Rail Data and Signal Surge Protection |
| Depth: | 107-107 |
| Height: | 4.33-4.33 |
