nVent UTB5DPM UTB REPLACEMENT MODULE FOR UTB5DP
$0.00
nVent #: UTB5DPM
SKU: NVENUTB5DPM
UPC: 782856622239
SKU: NVENUTB5DPM
UPC: 782856622239
| Complies With: | ANSI/IEEE C62.41.2-2002 Cat A, Cat B, Cat C |
| Enclosure Material: | UL 94V-0 Thermoplastic |
| Protection Modes: | Common |
| Technology: | Gas Discharge Tube (GDT) |
| Unit Weight (imperial) : | 0.050 lb |
| Temperature: | -20-65 |
| Max Discharge Current (Imax), L+L-PE: | 20 kA 8/20 s |
| Voltage Protection Level (Up), L-L: | 10 V @ 3 kA |
| Nominal System Voltage (Un): | 0 - 3 VAC |
| Max Continuous Operating Voltage (Uc): | 5 VAC |
| Frequency: | 0.5-0.5 MHz |
| Unit Weight: | 0.02-0.02 |
| Width (Imperial) : | 0.470 in |
| Loop Resistance: | 0.6-0.6 |
| Rated Load Current (IL): | 800 mA |
| Application: | Power Connections; Surge Protection |
| Standard: | CE |
| Type: | Replacement Modules for Universal Transient Barriers |
| Width: | 12-12 |
| Depth: | 43-43 |
| Height: | 65-65 |
