nVent DSD1101S150 SURGE DIVERTER,10KA SINGLE MODE,110-120V
$0.00
nVent #: DSD1101S150
SKU: NVENDSD1101S150
UPC: 782856470243
SKU: NVENDSD1101S150
UPC: 782856470243
| Enclosure Rating: | IP 20 |
| Max Continuous Operating Voltage (Uc): | 150 VAC |
| Enclosure Material: | UL 94V-0 Thermoplastic |
| Technology: | MOV with thermal disconnect |
| Remote Contacts: | No |
| Protection Modes: | Single |
| Nominal System Voltage (Un): | 110 - 120 V |
| Module Width: | 1 M |
| Distribution System: | TN-C |
| Temperature: | -40-176 |
| Frequency: | 0-60 |
| Max Discharge Current (Imax): | 10 kA 8/20 s |
| Short Circuit Current Rating (SCCR): | 10 |
| Nominal Discharge Current (In): | 5 kA 8/20 s |
| Unit Weight: | 0.13-0.13 |
| Application: | Surge Protection; Power Connections |
| Depth: | 68-68 |
| Mounting: | 35 mm top hat DIN rail |
| Type: | Surge Diverters |
| Width: | 18-18 |
| Height: | 3.54-3.54 |
